Citizen Science for Monitoring Birds

Overview

Developing novel spatiotemporal population dynamic models to detect range shifts

1. Overview

This document translates the NIMBLE implementation into a fully annotated mathematical model. The model has three components:

1. Process model — a latent, spatially and temporally varying true abundance $N_{i,t}$ for each spatial cell $i = 1,\dots,n_{\text{cells}}$ and time step $t = 1,\dots,n_{\text{time}}$, governed by an occupancy gate, a spatial Gaussian Predictive Process (GPP) for both baseline abundance and growth rate, and a shared annual growth pulse.
2. Three observation submodels — one per dataset (EBD, BBS, BCR), each with its own detection process linking the latent truth $N_{i,t}$ to the observed counts.
3. Priors and initial values — used to complete the Bayesian specification and to start the MCMC chains in a numerically stable region.

Notation: lower-case Roman/Greek letters are scalars or vectors; bracketed subscripts index cells $i$, time steps $t$, knots $k$, observations $n$/$k$, routes $r$, observers $o$, localities $l$, distance bands $d$, and removal intervals $r$ (BCR-specific, reused below since it never overlaps with route $r$). $\mathrm{N}(\mu,\sigma)$ denotes a normal distribution parameterized by its standard deviation (matching NIMBLE’s sd= convention), not variance.

2. Process Model: Latent Abundance Surface

2.1 Occupancy gate

Each spatial cell has a binary occupancy state:

$$z_i \sim \text{Bernoulli}(\zeta), \qquad \zeta \sim \text{Uniform}(0,1)$$

If $z_i = 0$, the cell is treated as structurally unoccupied and abundance collapses to a small numerical floor ($0.1$) rather than exactly zero, which keeps the Poisson rate strictly positive and avoids degenerate likelihood evaluations.

2.2 Initial abundance ($t=1$)

$$\lambda_{0,i} = \exp!\big(\beta_{\lambda 0} + s_{\lambda,i}\big)$$

$$N_{i,1} \sim \text{Poisson}!\Big(\lambda_{0,i}, z_i + 0.1,(1-z_i)\Big)$$

Here $\beta_{\lambda 0}$ is a global intercept on the log scale and $s_{\lambda,i}$ is the spatial deviation for cell $i$ described in Section 3. Occupied cells get a Poisson draw centered on the spatially-varying expected abundance; unoccupied cells get a near-zero floor.

2.3 Cell-specific long-run growth rate

$$\rho_i = \exp!\big(\beta_\rho + s_{\rho,i}\big)$$

$\beta_\rho$ is the global log-growth intercept and $s_{\rho,i}$ is a second, independently estimated spatial field (Section 3) that captures spatially structured tendencies in population trend:

• $s_{\rho,i} > 0 \Rightarrow \rho_i > $ overall average growth → candidate leading edge (range expansion)
• $s_{\rho,i} < 0 \Rightarrow \rho_i < $ overall average growth → candidate trailing edge (range contraction)

2.4 Dynamics for $t = 2,\dots,n_{\text{time}}$

$$N_{i,t} \sim \text{Poisson}!\Big(N_{i,t-1},\rho_i,\exp(\eta_t), z_i + 0.1,(1-z_i)\Big)$$

This is a separable space–time growth model: the realized growth multiplier at cell $i$, time $t$ is the product of

$$\underbrace{\rho_i}{\text{cell-specific, time-invariant}} \times \underbrace{\exp(\eta_t)}{\text{shared annual pulse, space-invariant}}$$

where $\eta_t$ is the year-level random effect described in Section 4. There is deliberately no space-by-time interaction term — a given year’s “good” or “bad” conditions ($\eta_t$) are assumed to act multiplicatively in the same direction everywhere, while persistent spatial gradients in growth ($\rho_i$) are fixed across years. This is a strong simplifying assumption worth stating explicitly when presenting the model: it rules out scenarios where, say, the leading edge booms in a year that the core declines.

3. Spatial Fields: Gaussian Predictive Process (GPP)

Estimating an independent spatial random effect at every one of $n_{\text{cells}}$ grid cells is computationally prohibitive for MCMC. The model instead uses a reduced-rank Gaussian Predictive Process: latent effects are estimated at a small set of $K = n_{\text{knots}}$ representative “knot” locations, and the value at any cell is obtained by a distance-weighted (kernel) interpolation from the knots. This is done independently for two latent surfaces — abundance ($\lambda$) and growth ($\rho$) — which happen to share the same spatial range parameter.

3.1 Knot-level effects

$$w_{\lambda,k} \sim \text{N}\big(0,\ \sqrt{\sigma^2_\lambda}\big), \qquad w_{\rho,k} \sim \text{N}\big(0,\ \sqrt{\sigma^2_\rho}\big), \qquad k = 1,\dots,K$$

$$\sigma^2_\lambda \sim \text{InvGamma}(2,1), \qquad \sigma^2_\rho \sim \text{InvGamma}(2,1)$$

These are i.i.d. across knots — all of the spatial smoothness comes from the kernel projection below, not from any correlation structure imposed directly on the $w$’s.

3.2 Kernel weights and shared range parameter

For every cell–knot pair, a weight decays exponentially with the pre-computed Euclidean (or geodesic) distance $d_{i,k}$:

$$\omega^{(\lambda)}{i,k} = \omega^{(\rho)}{i,k} = \exp!\left(-\frac{d_{i,k}}{\phi_s}\right), \qquad \phi_s \sim \text{Uniform}(0,,10^6)$$

The single shared range parameter $\phi_s$ encodes the assumption that abundance and growth-rate covary at the same spatial scale — i.e., whatever distance over which abundance is spatially autocorrelated is also the distance over which growth tendency is autocorrelated. Although the weight formulas are identical for $\lambda$ and $\rho$ (since $\phi_s$ is shared), they are tracked as separate quantities in the code for clarity and to allow future relaxation of this assumption (e.g., giving each field its own range parameter).

3.3 Normalized inverse-distance projection

The spatial deviation at each cell is a normalized, weighted average of the knot effects (inverse-distance weighting, IDW):

$$s_{\lambda,i} = \frac{\sum_{k=1}^{K} \omega^{(\lambda)}{i,k}, w{\lambda,k}}{\sum_{k=1}^{K} \omega^{(\lambda)}{i,k}}, \qquad s{\rho,i} = \frac{\sum_{k=1}^{K} \omega^{(\rho)}{i,k}, w{\rho,k}}{\sum_{k=1}^{K} \omega^{(\rho)}_{i,k}}$$

Because this is defined for every cell $i = 1,\dots,n_{\text{cells}}$ — sampled and unsampled alike — predictions to range cells with no direct survey coverage emerge automatically as a byproduct of fitting the model; no separate prediction step is required.

4. Temporal Random Effects

Three independent year-level random walks (technically, independent zero-mean normal deviates per year, not a true random walk) absorb temporal structure that is not attributable to the spatial growth surface:

Shared annual growth pulse (process model; Section 2.4), defined for $t=2,\dots,n_{\text{time}}$ since $t=1$ is the initial condition:

$$\eta_t \sim \text{N}(0,\ \sigma_\eta), \qquad \sigma_\eta \sim \text{Gamma}(2,10)$$

EBD annual detection effect (absorbs eBird’s well-documented growth in participation/effort over time, keeping it out of the abundance trend):

$$\delta^{\text{ebd}}t \sim \text{N}(0,\ \sigma{\delta,\text{ebd}}), \qquad \sigma_{\delta,\text{ebd}} \sim \text{Gamma}(2,10)$$

BBS annual detection effect (absorbs annual protocol/effort variation in BBS):

$$\delta^{\text{bbs}}t \sim \text{N}(0,\ \sigma{\delta,\text{bbs}}), \qquad \sigma_{\delta,\text{bbs}} \sim \text{Gamma}(2,10)$$

All three are defined for $t = 1,\dots,n_{\text{time}}$ except $\eta_t$, which starts at $t=2$. The $\text{Gamma}(2,10)$ prior on each standard deviation is weakly informative and keeps the year effects from running away to implausible magnitudes while still allowing real temporal signal to be detected.

5. Observation Submodel 1: Breeding Bird Survey (BBS)

BBS data consist of repeated stop-level counts along fixed roadside transects, repeated annually. Detection is allowed to vary by route, observer, position along the route (stop), whether the route is newly added, and year.

5.1 Random effects

$$\chi^{\text{route}}r \sim \text{N}(0,\ \sigma{\chi,\text{route}}), \quad r = 1,\dots,n_{\text{route}}$$

$$\chi^{\text{obs}}o \sim \text{N}(0,\ \sigma{\chi,\text{obs}}), \quad o = 1,\dots,n_{\text{obser}}^{\text{bbs}}$$

with $\sigma_{\chi,\text{route}}, \sigma_{\chi,\text{obs}} \sim \text{Gamma}(0.01, 0.01)$ — a diffuse, near-noninformative prior on each variance component.

5.2 Stop-position effect

Detectability is allowed to trend smoothly across the five stops within a route (bbs_stops rescaled to $[-2,2]$):

$$\sigma_{\chi}(s) = \exp!\big(\chi^{(1)}{\text{stop}} + \chi^{(2)}{\text{stop}}\cdot \text{stop}s\big), \qquad s = 1,\dots,n{\text{stop}}$$

with priors $\chi^{(1)}{\text{stop}} \sim \text{N}(0,10)$ and $\chi^{(2)}{\text{stop}} \sim \text{N}(0,10)$ truncated to be non-negative ($\chi^{(2)}_{\text{stop}} \ge 0$). This is a dispersion parameter (it scales the standard deviation of a downstream normal, not a mean), so forcing it non-negative is a sensible identifiability constraint that prevents the implied stop-level variance from decreasing with stop number in an uninterpretable way… more precisely, it constrains the direction of the trend in dispersion across stops to be monotonic in a single, identifiable direction.

5.3 Linear predictor for mean log-detection rate

For each BBS observation $n = 1,\dots,n_{\text{obs}}^{\text{bbs}}$ (a route-by-year combination):

$$\mu^{\chi}n = \chi\mu + \chi^{\text{route}}{r[n]} + \chi^{\text{obs}}{o[n]} + \chi_{\text{new}}\cdot \text{new}n + \delta^{\text{bbs}}{t[n]}$$

with priors $\chi_\mu \sim \text{N}(0,10)$ (global intercept) and $\chi_{\text{new}} \sim \text{N}(0,10)$ (adjustment for newly-established BBS routes, which often show atypical early-year detection).

5.4 Stop-level detection rate and likelihood

$$\log \chi_{n,s} \sim \text{N}\big(\mu^{\chi}n,\ \sigma\chi(s)\big), \qquad \chi_{n,s} = \exp(\log \chi_{n,s})$$

$$y^{\text{bbs}}{n,s} \sim \text{Poisson}\Big(N{i[n],,t[n]}\cdot \chi_{n,s}\Big)$$

Note the extra layer of randomness here: rather than treating $\chi_{n,s}$ as a deterministic function of the linear predictor, the model draws $\log \chi_{n,s}$ from a normal distribution centered on the linear predictor, with stop-specific dispersion $\sigma_\chi(s)$. This over-dispersion term absorbs stop-to-stop variability in detectability beyond what the fixed/random effects capture, and is itself estimated as a free parameter per observation–stop combination (log_chi is an $n_{\text{obs}}^{\text{bbs}} \times n_{\text{stop}}$ matrix of latent parameters).

6. Observation Submodel 2: eBird (EBD)

EBD is opportunistic, citizen-science data: stationary or traveling counts submitted voluntarily, with highly variable effort. The model uses a zero-inflated Poisson to separate “the species was present but the count reflects effort/detectability” from “the species was structurally absent from this particular checklist’s conditions” (e.g., off-habitat point within a coarse grid cell).

6.1 Nested random effects (cell → locality)

$$\omega^{\text{cell}}c \sim \text{N}(0,\ \sigma{\omega,\text{cell}}), \quad c = 1,\dots,n_{\text{cells}}, \qquad \sigma_{\omega,\text{cell}} \sim \text{Gamma}(0.01,0.01)$$

$$\omega^{\text{locality}}l \sim \text{N}\big(\omega^{\text{cell}}{c[l]},\ \sigma_{\omega,\text{loc}}\big), \quad l = 1,\dots,n_{\text{localities}}, \qquad \sigma_{\omega,\text{loc}} \sim \text{Gamma}(0.01,0.01)$$

$$\omega^{\text{obs}}o \sim \text{N}(0,\ \sigma{\omega,\text{obs}}), \quad o = 1,\dots,n_{\text{obser}}^{\text{ebd}}, \qquad \sigma_{\omega,\text{obs}} \sim \text{Gamma}(0.01,0.01)$$

The locality effect is centered on its parent cell’s effect rather than on zero — this is a genuine hierarchical (nested) structure, distinct from the independent route/observer effects in the BBS submodel. It reflects that eBird checklists at specific localities within a grid cell should detect similarly to the cell average, with locality-specific deviations layered on top.

6.2 Linear predictor for expected detection-scaled count

$$\omega_k = \exp\Big( \omega^{(1)} + \omega^{(2)} \cdot \text{duration}_k + \omega^{(3)} \cdot \text{nobservers}_k

• \omega^{\text{cell}}{c[k]} + \omega^{\text{locality}}{l[k]} + \omega^{\text{obs}}{o[k]} + \delta^{\text{ebd}}{t[k]} \Big)$$

for each checklist $k = 1,\dots,n_{\text{obs}}^{\text{ebd}}$, with $\boldsymbol{\omega}^{(1:3)} \sim \text{N}(0,10)$ (intercept, duration effect, party-size effect).

6.3 Zero-inflation and likelihood

$$z^\omega_k \sim \text{Bernoulli}(\zeta_\omega), \qquad \zeta_\omega \sim \text{Uniform}(0,1)$$

$$y^{\text{ebd}}k \sim \text{Poisson}\Big(N{c[k],,t[k]}\cdot \omega_k \cdot z^\omega_k + \delta_\omega,(1-z^\omega_k)\Big), \qquad \delta_\omega \sim \text{Gamma}(0.01,0.01)$$

When $z^\omega_k = 1$ (the “structural presence” state), the expected count scales with true abundance $N$ and the detection multiplier $\omega_k$ as in a standard N-mixture model. When $z^\omega_k = 0$, the expected count collapses to a small residual rate $\delta_\omega$, representing checklists where the species was effectively unavailable for detection regardless of $N$. Note this is a second, independent zero-inflation/occupancy process from $z_i$ in the process model — $\zeta_\omega$ operates at the checklist level on detectability, while $\zeta$ in Section 2.1 operates at the cell level on true presence.

7. Observation Submodel 3: IMBCR (BCR) — Distance + Removal Sampling

BCR surveys combine distance sampling (birds detected within concentric distance bands) and time-removal sampling (birds detected within sequential time intervals), giving a two-dimensional detection process.

7.1 Distance-sampling component (half-normal detection function)

With $n_{\text{dist}}=2$ pre-defined distance bands (0–125 m, 125–250 m; bounds passed in as constants bcr_low/bcr_high to avoid an off-by-one indexing issue in NIMBLE) and truncation radius $w = 250$ m:

$$\text{intval}(d) = \sigma^2\left[\exp!\left(-\frac{\text{low}_d^2}{2\sigma^2}\right) - \exp!\left(-\frac{\text{high}_d^2}{2\sigma^2}\right)\right]$$

$$\psi_d = \frac{2,\text{intval}(d)}{w^2}, \qquad \psi_{\text{sum}} = \sum_{d=1}^{n_{\text{dist}}}\psi_d, \qquad \psi_d^{\text{prop}} = \frac{\psi_d}{\psi_{\text{sum}}}$$

with $\sigma \sim \text{Uniform}(10,500)$, the half-normal scale parameter governing how quickly detectability decays with distance. (The model deliberately uses a $\text{Uniform}$ rather than a vague Gamma prior here, since a $\text{Gamma}(0.01,0.01)$ would place near-zero prior density around plausible values of $\sigma$ such as 60.) $\psi_{\text{sum}}$ is the overall probability that an individual within the truncation radius is detected at all (integrated over distance), and $\psi_d^{\text{prop}}$ is the conditional probability of being detected in band $d$ given detection at all.

7.2 Removal-sampling component (geometric distribution)

With $n_{\text{time}}^{\text{bcr}} = 6$ removal intervals:

$$\phi_r = (1-\theta)^{,r-1},\theta, \qquad \phi_{\text{sum}} = \sum_{r=1}^{6}\phi_r, \qquad \phi_r^{\text{prop}} = \frac{\phi_r}{\phi_{\text{sum}}}$$

with $\theta \sim \text{Uniform}(0,1)$, the per-interval probability of first detection (a standard geometric/removal model: an individual not yet detected in intervals $1,\dots,r-1$ is detected in interval $r$ with probability $\theta$). $\phi_{\text{sum}}$ would be the cumulative probability of eventual detection across all 6 intervals; $\phi_r^{\text{prop}}$ renormalizes to a proper conditional distribution over intervals given eventual detection.

7.3 Joint cell probabilities

Assuming distance and removal-time are independent detection axes, the joint probability of observation in distance band $d$ and removal interval $r$, conditional on detection, is the product:

$$\pi_{(r-1)\cdot n_{\text{dist}} + d} = \psi_d^{\text{prop}} \cdot \phi_r^{\text{prop}}$$

(indexed in distance-major order to match the flattened bcr_cnt matrix in code).

7.4 Likelihood: binomial detection + multinomial allocation

For each BCR point count $k = 1,\dots,n_{\text{obs}}^{\text{bcr}}$:

$$S_k \sim \text{Binomial}\big(\psi_{\text{sum}},\ N_{i[k],,t[k]}\big)$$

$$\big(y^{\text{bcr}}{k,1},\dots,y^{\text{bcr}}{k,12}\big) \sim \text{Multinomial}\big(\boldsymbol\pi,\ S_k\big)$$

This two-stage construction is the standard way to combine distance and removal/time-of-detection sampling: $S_k$ is the total number of the $N$ individuals present that were detected at all (governed purely by the distance-sampling detection probability $\psi_{\text{sum}}$), and the multinomial then allocates those $S_k$ detections across the $2 \times 6 = 12$ distance-by-time cells according to the joint detection profile $\boldsymbol\pi$. Note that $\phi_{\text{sum}}$ (cumulative removal-detection probability) is not used directly in the binomial step — the removal/time component is fully conditional on having already been detected (distance-wise) and enters only through the multinomial allocation, not as a second independent detection filter on $N$.

8. Summary of Parameters and Priors

Parameter	Role	Prior
$\zeta$	cell occupancy probability	$\text{Unif}(0,1)$
$\beta_{\lambda0}$	log-abundance intercept	$\text{N}(0,10)$
$\beta_\rho$	log-growth intercept	$\text{N}(0,10)$
$\phi_s$	shared spatial range	$\text{Unif}(0,10^6)$
$\sigma^2_\lambda,\ \sigma^2_\rho$	spatial field variances	$\text{InvGamma}(2,1)$
$w_{\lambda,k},\ w_{\rho,k}$	knot-level spatial effects	$\text{N}(0,\sqrt{\sigma^2_\cdot})$
$\sigma_\eta$	SD of annual growth pulse	$\text{Gamma}(2,10)$
$\eta_t$	annual growth pulse	$\text{N}(0,\sigma_\eta)$
$\sigma_{\delta,\text{ebd}},\ \sigma_{\delta,\text{bbs}}$	SD of annual detection effects	$\text{Gamma}(2,10)$
$\delta^{\text{ebd}}_t,\ \delta^{\text{bbs}}_t$	annual detection effects	$\text{N}(0,\sigma_{\delta,\cdot})$
$\chi_\mu,\ \chi_{\text{new}}$	BBS detection intercept, new-route effect	$\text{N}(0,10)$
$\sigma_{\chi,\text{route}},\ \sigma_{\chi,\text{obs}}$	BBS route/observer SDs	$\text{Gamma}(0.01,0.01)$
$\chi^{(1)}{\text{stop}},\ \chi^{(2)}{\text{stop}}$	stop-position dispersion coefficients	$\text{N}(0,10)$; $\chi^{(2)} \ge 0$
$\omega^{(1:3)}$	EBD detection intercept, duration, party-size effects	$\text{N}(0,10)$
$\sigma_{\omega,\text{cell}},\sigma_{\omega,\text{loc}},\sigma_{\omega,\text{obs}}$	EBD variance components	$\text{Gamma}(0.01,0.01)$
$\zeta_\omega$	EBD zero-inflation probability	$\text{Unif}(0,1)$
$\delta_\omega$	EBD residual rate when “absent”	$\text{Gamma}(0.01,0.01)$
$\sigma$	BCR half-normal distance scale	$\text{Unif}(10,500)$
$\theta$	BCR per-interval removal probability	$\text{Unif}(0,1)$

9. Initial Values: Rationale

9.1 Latent abundance $N_{i,t}$ and occupancy $z_i$

Initial values for $N$ are constructed empirically rather than drawn from the prior, which is standard practice for discrete/count latent states in MCMC — a poor starting value (especially one below the observed count) can cause an immediate likelihood violation (zero density) and prevent the sampler from ever moving.

The construction:

1. For every cell $\times$ year combination, sum observed counts across all three datasets (eBird sightings, BBS stop totals, BCR multinomial totals).
2. Inflate the BCR contribution by the estimated overall detection probability $\hat\psi_{\text{sum}} \approx 0.115$: $\text{BCR}{\text{implied}} = \lceil \text{BCR}{\text{raw}} / 0.115 \rceil + 5$, since BCR is the only one of the three datasets with an explicit, well-calibrated absolute detection-probability estimate, making it the most reliable basis for back-calculating a plausible true abundance.
3. Take the cell/year total as $\max(\text{summed raw counts},\ \text{BCR-implied count})$.
4. Add a buffer of $5$ and floor at $5$: $N_{i,1}^{\text{init}} = \max(\text{total}+5,\ 5)$.

This guarantees $N_{i,t}^{\text{init}} \ge$ every observed count at every cell/time combination (avoiding “negative binomial-type” violations where a Poisson/Binomial observation model is asked to explain more detections than the assumed population size), while still being a finite, well-scaled starting point rather than an arbitrarily huge value that would slow burn-in.

Occupancy is initialized deterministically from the same matrix:

$$z_i^{\text{init}} = \begin{cases} 0 & \text{if } \sum_t N_{i,t}^{\text{init}} = 0 \ 1 & \text{otherwise} \end{cases}$$

9.2 Spatial fields

Knot-level effects start at the flat-field null: $w_{\lambda,k}^{\text{init}} = w_{\rho,k}^{\text{init}} = 0$ for all $k$, with $\sigma^2_{\lambda},\sigma^2_\rho$ both initialized at $0.5$. The shared range parameter $\phi_s$ is initialized at roughly one-third of the spatial domain’s extent (a typical rule-of-thumb starting value for spatial range parameters, large enough to let the sampler explore both short- and long-range solutions without immediately collapsing to near-zero or near-infinite range).

9.3 Temporal and detection random effects

All year-level random effects ($\eta_t$, $\delta^{\text{ebd}}_t$, $\delta^{\text{bbs}}_t$) and their SD hyperparameters start at $0$ and $0.1$ respectively — a minimal-signal starting point that lets the data pull the chain toward whatever temporal structure is actually supported.

9.4 Observation-model initial values

• BBS: $\chi_\mu^{\text{init}} = -5$ (a small baseline detection rate on the log scale), route/observer random effects at $0$, stop-dispersion intercept/slope at $(-1, 0.1)$, and the full latent log_chi matrix initialized at $-5$ everywhere — a conservative, low-detection-rate starting surface that is then refined by the data.
• EBD: detection intercept $-6$ with small positive effort coefficients $(0.5, 0)$; zero-inflation indicators $\omega_{z,k}^{\text{init}}$ set deterministically from the data ($1$ if the observed count was $>0$, $0$ otherwise) — again a data-informed start that avoids contradicting the observed counts at $t=0$ of the chain.
• BCR: $\sigma^{\text{init}} = 60$ m (a biologically plausible half-normal scale for a passerine point count) and $\theta^{\text{init}} = 0.4$ (a moderate per-interval removal probability).
